Hunza Direct Burial Arch Bollard Square Light

Original price was: $239.99.Current price is: $159.78.

Sale!

49 in stock

SKU: BOL/ARCSQ-R-EBK-TYP2-2 Category:
Share

Hunza Direct Burial Arch Bollard Square Light

The Arch Bollard is ideal for commercial application. Best suited for ground lighting on driveways and pathways. It has a minimal, contemporary aesthetic that will blend into any architectural setting. This luminaire features a Type II optic that casts a very long but narrow downwards illumination, or Type IV optic which gives a forward throw beam pattern. The result is an extremely low glare light fitting with precise light placement.

Product Specifications

Lumen Output*
  • 3000 lumens @ 700mA (26 Watts)
Lumens Per Watt (lm/W)**Delivered from the Luminaire with an unobstructed beam.
  • 100 lm/W
Luminaire Options
  • Arch Bollard Square – Direct Burial
Warranty
  • *Excludes third party lamps and power supplies*
  • Aluminium Components – 5 years
  • Electronics – 5 Years
Power Options
  • 700mA CC Input – Series Wired – Remote Driver 37Vf 25.9W
  • 24VDC Input – Parallel Wired 25.9W
  • 110-277 VAC – Retro Integral Driver 25.2W
Lens Options
  • with Clear Lens
Mounting Options
  • with Mounting Cage*
LED
  • Cree™ CXB 1830 Plug and Play field replaceable LED board
LED Life Expectancy
  • 50,000 Hrs @ L70
CRI
  • 80 Optional
  • 90+ Standard
Ingress Protection
  • IP66
Impact Protection
  • IK10
Materials
  • Solid Powder Coated Aluminium
Standards
  • IEC/BS/AS/NZ 60598
  • UL 1598
  • UL 2108
  • UL 1838
  • CE
Recommended Power Supplies
  • Driver Supplied for Series Remote Wired (CC format)
  • 24VDC Power Supply Required for 24VDC Input ( CV format )
  • No Driver Required for Retro™ ‘R ( 120/240V Input )
Product Files

Click for Arch Bollard Square BOLARCSQ Specification Sheet

Click for Hunza ARCH Bollard Square – BOLARCSQ – Product Diagram

Click for Guide: Flange Mount Template and Mounting Cage

Click for Hunza ARCH Bollard Installation Instructions – USA

Click for Hunza ARCH Bollard Installation Instructions – INTERNATIONAL

Diagram Image
Select Material

Black, Bronze, Dark Grey, Corten, Olive Green, Silver Star, Arctic White, Fine Silver, White Birch
Select Beam Angle

Type 2 Optic, Type 4 Optic, 95 Degree
Select Colour Temperature

2700K, 3000K, 4000K
