Hunza Floor Light Square

Original price was: $239.99.Current price is: $138.31.

Sale!

96 in stock

SKU: FLSQ/L-D3-SS-15-2 Categories: ,
Share

Hunza Floor Light Square

The Floor Light Square is an uplighter luminaire which has a low profile of 7mm. The square shape makes it ideal for mounting in tiled areas and it can be walked upon without being damaged.  All Floor Lights are supplied with a mounting canister.

Product Specifications

Lumen Output*
  • 1050 lumens @ 600mA (6 Watts)
  • 420 lumens @ 700mA (4 Watts)
  • 240 lumens @ 350mA (2 Watts)
Lumens Per Watt (lm/W)**Delivered from the Luminaire with an unobstructed beam.
  • 100 lm/W
Lens Options
  • with Clear Lens
  • with Frosted Lens
  • with Clear Lens and Hex Cell Louvre
Mounting Options
  • Deck Mount Canister – Aluminium
  • Floor Light Canister
  • Floor Light Canister 200mm
  • Stainless Steel Canister
LED
  • Cree™ XHP-50-2 Plug and Play field replaceable LED board
LED Life Expectancy
  • 50,000 Hrs @ L70
CRI
  • 90+ Standard
Ingress Protection
  • IP67
Materials
  • 316 Marine Grade Stainless Steel
  • Solid Copper
Warranty
  • *Excludes third party lamps and power supplies*
  • 316 Stainless Steel Components – 10 years
  • Electronics – 5 Years
  • Solid Copper Components – 10 Years
Standards
  • IEC/BS/AS/NZ 60598
  • UL 2108
  • UL 1838
  • CE
Recommended Power Supplies
  • Driver Required for Series Wired (CC format)
  • 24VDC Power Supply Required for 24VDC Input ( CV format )
  • Transformer Required for 12VAC Parallel Wired ( CV format )
Product Files

Click for Floor Light Square – FLSQ-L – Specification Sheet

Click for Floor Light Square – FLSQ-L – Product Diagram

Click for Path Light – Step Light – Floor Light – Installation Instructions USA

Click for Path Light – Step Light – Floor Light – Installation Instructions International

Diagram Image
Select Power Options // Select Material // Select Beam Angle // Select Colour Temperature

12V 2.1W // 316 Marine Grade Stainless Steel // 15 Degree // 2700K, 12V 2.1W // 316 Marine Grade Stainless Steel // 15 Degree // 3000K, 12V 2.1W // 316 Marine Grade Stainless Steel // 15 Degree // 4000K, 12V 2.1W // 316 Marine Grade Stainless Steel // 25 Degree // 2700K, 12V 2.1W // 316 Marine Grade Stainless Steel // 25 Degree // 3000K, 12V 2.1W // 316 Marine Grade Stainless Steel // 25 Degree // 4000K, 12V 2.1W // 316 Marine Grade Stainless Steel // 38 Degree // 2700K, 12V 2.1W // 316 Marine Grade Stainless Steel // 38 Degree // 3000K, 12V 2.1W // 316 Marine Grade Stainless Steel // 38 Degree // 4000K, 12V 2.1W // 316 Marine Grade Stainless Steel // 60 Degree // 2700K, 12V 2.1W // 316 Marine Grade Stainless Steel // 60 Degree // 3000K, 12V 2.1W // 316 Marine Grade Stainless Steel // 60 Degree // 4000K, 12V 2.1W // Solid Copper // 15 Degree // 2700K, 12V 2.1W // Solid Copper // 15 Degree // 3000K, 12V 2.1W // Solid Copper // 15 Degree // 4000K, 12V 2.1W // Solid Copper // 25 Degree // 2700K, 12V 2.1W // Solid Copper // 25 Degree // 3000K, 12V 2.1W // Solid Copper // 25 Degree // 4000K, 12V 2.1W // Solid Copper // 38 Degree // 2700K, 12V 2.1W // Solid Copper // 38 Degree // 3000K, 12V 2.1W // Solid Copper // 38 Degree // 4000K, 12V 2.1W // Solid Copper // 60 Degree // 2700K, 12V 2.1W // Solid Copper // 60 Degree // 3000K, 12V 2.1W // Solid Copper // 60 Degree // 4000K, 12V 4.2W // 316 Marine Grade Stainless Steel // 15 Degree // 2700K, 12V 4.2W // 316 Marine Grade Stainless Steel // 15 Degree // 3000K, 12V 4.2W // 316 Marine Grade Stainless Steel // 15 Degree // 4000K, 12V 4.2W // 316 Marine Grade Stainless Steel // 25 Degree // 2700K, 12V 4.2W // 316 Marine Grade Stainless Steel // 25 Degree // 3000K, 12V 4.2W // 316 Marine Grade Stainless Steel // 25 Degree // 4000K, 12V 4.2W // 316 Marine Grade Stainless Steel // 38 Degree // 2700K, 12V 4.2W // 316 Marine Grade Stainless Steel // 38 Degree // 3000K, 12V 4.2W // 316 Marine Grade Stainless Steel // 38 Degree // 4000K, 12V 4.2W // 316 Marine Grade Stainless Steel // 60 Degree // 2700K, 12V 4.2W // 316 Marine Grade Stainless Steel // 60 Degree // 3000K, 12V 4.2W // 316 Marine Grade Stainless Steel // 60 Degree // 4000K, 12V 4.2W // Solid Copper // 15 Degree // 2700K, 12V 4.2W // Solid Copper // 15 Degree // 3000K, 12V 4.2W // Solid Copper // 15 Degree // 4000K, 12V 4.2W // Solid Copper // 25 Degree // 2700K, 12V 4.2W // Solid Copper // 25 Degree // 3000K, 12V 4.2W // Solid Copper // 25 Degree // 4000K, 12V 4.2W // Solid Copper // 38 Degree // 2700K, 12V 4.2W // Solid Copper // 38 Degree // 3000K, 12V 4.2W // Solid Copper // 38 Degree // 4000K, 12V 4.2W // Solid Copper // 60 Degree // 2700K, 12V 4.2W // Solid Copper // 60 Degree // 3000K, 12V 4.2W // Solid Copper // 60 Degree // 4000K, 12V 6.3W // 316 Marine Grade Stainless Steel // 15 Degree // 2700K, 12V 6.3W // 316 Marine Grade Stainless Steel // 15 Degree // 3000K, 12V 6.3W // 316 Marine Grade Stainless Steel // 15 Degree // 4000K, 12V 6.3W // 316 Marine Grade Stainless Steel // 25 Degree // 2700K, 12V 6.3W // 316 Marine Grade Stainless Steel // 25 Degree // 3000K, 12V 6.3W // 316 Marine Grade Stainless Steel // 25 Degree // 4000K, 12V 6.3W // 316 Marine Grade Stainless Steel // 38 Degree // 2700K, 12V 6.3W // 316 Marine Grade Stainless Steel // 38 Degree // 3000K, 12V 6.3W // 316 Marine Grade Stainless Steel // 38 Degree // 4000K, 12V 6.3W // 316 Marine Grade Stainless Steel // 60 Degree // 2700K, 12V 6.3W // 316 Marine Grade Stainless Steel // 60 Degree // 3000K, 12V 6.3W // 316 Marine Grade Stainless Steel // 60 Degree // 4000K, 12V 6.3W // Solid Copper // 15 Degree // 2700K, 12V 6.3W // Solid Copper // 15 Degree // 3000K, 12V 6.3W // Solid Copper // 15 Degree // 4000K, 12V 6.3W // Solid Copper // 25 Degree // 2700K, 12V 6.3W // Solid Copper // 25 Degree // 3000K, 12V 6.3W // Solid Copper // 25 Degree // 4000K, 12V 6.3W // Solid Copper // 38 Degree // 2700K, 12V 6.3W // Solid Copper // 38 Degree // 3000K, 12V 6.3W // Solid Copper // 38 Degree // 4000K, 12V 6.3W // Solid Copper // 60 Degree // 2700K, 12V 6.3W // Solid Copper // 60 Degree // 3000K
